Bike Specifications

Available Sizes

S/M, M/L, L/XL

Color

Black Lava / Mercury / Chrome

Frame & Suspension

Frame
Advanced-grade composite frame featuring both front and rear triangles built for downhill performance. The frame includes 200mm of Maestro suspension travel and multiple geometry adjustment options using flip chips at the headset, dropout (DH), and Maestro 3 system. It uses a 12×157mm thru-axle for increased stiffness and is compatible with either 27.5-inch or 29-inch rear wheels.

Front Suspension

Fox 40 Factory Fork

• GRIP X2 damper

• 203mm travel

• 20×110 axle spacing

• Built for high-speed downhill control and durability

Rear Suspension

Fox DHX2 Factory Coil Shock

• SLS coil spring

• Size: 225 × 75

• Custom-tuned specifically for Giant frames

Spring rates by frame size:

• S/M: 425 lb

• M/L: 450 lb

• L/XL: 475 lb

Cockpit

Handlebar
Giant Contact SL TR35
800mm width
35mm clamp diameter
20mm rise

Grips
Giant Tactal Pro Single Lock-On

Stem
TruVativ Descendant Direct Mount
35mm clamp diameter
50mm length (all sizes)

Seat Components

Seatpost
Giant Contact
30.9mm diameter
0mm offset
400mm length

Saddle
Giant Romero

Drivetrain

Shifters
SRAM GX Eagle DH
7-speed drivetrain

Rear Derailleur
SRAM GX Eagle DH

Front Derailleur
Not applicable (1x drivetrain)

Cassette
SRAM GX DH
11–25T gear range

Chain
SRAM PC1110

Crankset
TruVativ Descendant DH
34T chainring
56.5mm chainline

Crank lengths by frame size:

• S/M: 165mm

• M/L: 170mm

• L/XL: 170mm

Bottom Bracket
SRAM DUB threaded
83mm width

Braking System

Brakes
Shimano Saint M820 hydraulic disc brakes

Brake Levers
Shimano Saint BL-M820

Brake Rotors

• Front: 220mm Shimano RT-66

• Rear: 203mm Shimano RT-66

This powerful braking setup provides maximum stopping power for downhill riding.

Wheels

Rims
Giant TRA 2 rims
6061 aluminum alloy construction
Hookless rim design with Wide Guard Technology

Rim specifications:

• 30mm inner width

• 40mm outer width

• 21mm rim height

Hubs

Front Hub
Giant MTB alloy hub
6-bolt disc mount

Rear Hub
Giant MTB alloy hub
30-tooth 3-pawl driver
6-bolt disc mount

Spokes
Stainless steel spokes

Tires

Front Tire
Maxxis Assegai
29 × 2.5 WT
3C MaxxGrip compound
DH casing
Tubeless Ready

Rear Tire
Maxxis Minion DHR II
27.5 × 2.4 WT
3C MaxxGrip compound
DH casing
Tubeless Ready

Additional Features

• Tubeless-ready wheel system

• Maximum tire clearance: 2.5 inches

• Maximum chainring size: 36T

• MRP SXg chain guide included

• Full down tube protector for extra frame protection

Weight

Approximate weight:
16.41 kg (36 lb 2 oz) – Size M/L
